Image Sensor 1/3" SHARP
Horizontal Resolution 600TVL, Low Illumination
Pixels PAL:752(H)×582(V),
NTSC:768(H)×494(V)
TV System PAL/NTSC
Lens Board Lens 3.6mm/F2.0
Sync System Internal
Usable Illumination 0.01Lux/F2.0
S/N Ratio ≥48dB (AGC OFF)
Gamma Correction 0.45
Video Out Composite Signal (1.0Vp-p, 75Ω)
Scanning System PAL:625 Lines, 50 Field/Sec;NTSC:525 Lines, 60 Field/Sec
Electronic Shutter Time Auto:PAL 1/50-1/100, 000Sec;NTSC 1/60-1/100, 000Sec
Operation Temperature -10℃ ~ +50℃ RH95% Max
Storage Temperature -20℃ ~ +60℃ RH95% Max
White Balance Auto
Power Source DC12V 150mA
Dimension ￠94x 85(H) mm
Package 52*39*28mm 24PCS/CTN
Weight 650g
