Package Contents
* 4-Channel DVR

* IR cameras X 4 (with 3.6mm Fixed Lens)

* User Manual

* Software CD

* Camera Cables x 4 (60 ft)

* Power Supply for DVR

* 4-way Splitter Cable

* Cameras Stands x 4

* Remote Control

* Mouse
Dimensions (Package)
* 14.30" x 7.75" x 16"
Weight (Package)
* 16.06 lbs

CAMERAS
Image Sensor
* 1/4" PIXEL PLUS CCD
Minimum Illuminance
* 0 LUX with 24 x IR LEDs
Signal System
* NTSC
Lens
* 3.6mm Fixed Lens
Resolution
* 600TVL
Dimensions
* 2.68" x 3.62"x 2.68"
Operation Temperature
* 14°F~ 104°F
Video Output
* 1.0 Vp-p, 75 Ohms
Electronic Shutter
* 1/50(1/60) - 1/100,000 second
S/N Ratio
* >= 48db
DIGITAL VIDEO RECORDER
Compression
*H.264
Video Input
* BNC 4-Channel Inputs
Video Output
* BNC x 1 and VGA
Audio
* RCA Inputs and Output
Display Resolution
* NTSC: 720 x 480; PAL: 720 x 576
Display Frame Rate
* NTSC: 120fps; PAL: 100fps
Record Resolution
* NTSC: 720 x 240/ 360 x 240 ; PAL: 720 x 288/ 360 x 288
Record Frame Rate
* NTSC: 120fps; PAL: 100fps
HDD Interface
* Hard Drive (500GB), Max. up to 2TB
Record Modes
* Continuous, Motion Detection, Sensor Triggered, Time Schedule
Record Picture Quality
* Best, Fine, Normal
Channel Playback
* Up To 4 Channels
Network Interface
* RJ45, TCP/IP
Network Remote Users
* Up to 10 Users Simultaneously
USB Interface
* USB 2.0 x 2 (Mouse and Thumb Drive)
Backup Device
* USB 2.0 Thumb Drive
Remote Control
* IR Remote Control
Power Supply
* DC 12V (Adapter Included)
